ExceptionalPerformance
Equipped with the cuting-edge lmpinjE710 chip and proprietary algorithms, it achieves anexceptional read accuracy of up to 99.9%.
Anti Cross-ReadRobust metal casing prevents signal leakage, significantly improving readingaccuracy while preventing cross-reads.
Versatile Power Options
Supports USB power supply, with optional PoE supply. Data transmission and powersupply can be easily achieved with a single USB Type-C cable or RJ45 Ethernet,effectively reducing deployment and maintenance costs.
Flexible connectivity Options
Standard Type-C USB 2.0 interface, with Bluetooth 5.0 and RJ45 Ethemet connectivityIt can seamlessly connect and communicate with devices running different operatingsystems such as Windows, Android, and iOS.
Full-Frequency UHF Tag Read & Write
Supports multiple operating frequencies and the 1S0 18000-6C (EPC C1G2)international protocol, meeting the requirements for full-frequency UHF tagreading and writing.
Dual Reading Feedback Modes
Built-in LED indicator and buzzer provide real-time reading feedback, preventingtags read miss.
Retail
Health Сare
Warehousing & Distribution
Entertainment & Service Industry
Dimensions
325mmx325mmx20mm
Weight
1850g
Frequency
840~960MHz (can be custom designed)
Protocol
IS018000-6C(EPC C1G2)
Output Power
0~30dBm(adjustable)
Read Range
Built-in antenna 0-50cm
Power Supply
Type-C interface, USB powered; PoE power supply(optional)
Communication
Type-C USB 2.0 connection, BT5.0, Ethernet
Indicator LED
BT connection status(blue);
Working(red)
Flash when data transmitted;
Power(red)
Buzzer
Sound when scanning tags
Sealing
IP54
Environmental
Operating temperature:-20'c ~+50°C
Storage temperature:-40'c~ +70°C
Humidity:5%RH~95%RH(non-condensing)
ESD:+15kV air discharge,+8kV direct discharge
