Ethernet port not included by default; Bluetooth & Wi-Fi available as options
Performs integrated printing and RFID encoding, no extra label rewinding operation required
Handles RFID media with minimum 15mm pitch, supporting flexible thick anti-metal labels within 1.3mm
Broad compatibility with standard RFID tags and flexible anti-metal labels
Support Alien, NXP, Impinj chip tags
Label inlay On-Pitch gap minimum 15mm (0.625")
Built-in counter to track the correct and wrong label
Support RFID password to Lock/Unlock
Bad label auto remarked during printing, support re-writing label times
Compatible with RFID industry printing command
RFID standard protocol UHF EPC Class1 Gen2/ISO18000-6C
Support USB and network bi-directional communication, to get printer real-time status
Health Сare
Manufacturing
Warehousing & Distribution
Resolution
GA-2408TE: 8 dots/mm (203DPI)
GA-3406TE: 12 dots/mm (300DPI)
Printing Method
Thermal Transfer & Direct Thermal
Max. Print Speed
GA-2408TE: 203mm(8")/second
GA-3406TE: 152mm(6")/second
Max. Print Width
GA-2408TE: 104mm (4.09")
GA-3406TE: 108mm (4.25")
Max. Print Length
GA-2408TE: 15,000mm (600")
GA-3406TE: 6800mm (267.7")
CPU
500 MHZ, 32 bits, COTEXT-M7
Interface
• USB 2.0 High Speed 480Mbps
• Internal Bluetooth 4.2 (factory option)
• Internal Wi-Fi 2.4G + Bluetooth 4.2 (factory option)
Sensors
Lid sensor, ribbon sensor, reflective sensor (mobile), penetrating sensor
Power
Externalvoltage automatic switching power supply
Input:AC100-240V,2.5A,50-60Hz.0utput: DC 24V,2.5A,60W
User Interface
• 1 power switch
• 1 buttons(Feed)
• 5 LEDs(Online blue light, Error red light, Ribbon green light, Communication orange light, Press-key white light )
Internal Fonts
• 8 alpha-numeric bitmap fonts
• True type font engine (need to download scalable font file)
1D Barcode
Code11,Code 39,Code 93,Code 128 (subsets A, B,C),UPC-A, UPC-EUCC-128,Codabar, EAN/JAN-8,EAN/JAN-13, Interleaved 2 of 5
2D Barcode
QR Code, Micro QR Code, PDF417, Micro PDF417, Grid Matrix, MaxiCodeAztec Code, Data Matrix
Rotation
Font and barcode support 0, 90, 180, 270 degree rotation
Printer Language
Compatible to TSPL, ZPL, ZPL II
Media Type
Continuous, die-cut, black mark, fan-fold
Media Width
20~118 mm (0.7" ~ 4.6")
Media Thickness
0.06~1.3mm
Media Core Diameter
25.4 mm (1")
Label Roll Capacity
127 mm (5") OD
Physical Dimension
280mm(L) x 190mm(W) x 198.3mm(H)
Net Weight
2.7kg
Enclosure
Double-layer ABS plastic
Ribbon
300 meters long, max. OD 67 mm, 1" core (ink coated outside)
Ribbon Width
30~110mm (1.18"~4.3")
Environment Condition
Operation: 5 ~ 40°C, 25 ~ 85% non-condensing
Storage: -40 ~ 60°C, 10 ~ 90% non-condensing
Environmental Concern
Comply with RoHS, REACH, WEEE
