Specification

• Model

  GP-D330FAX
  GP-D320FAX

• Print Method

  Direct Thermal

• Emulation

  TSPL、ESC/POS

• Resolution

  300DPI(GP-D330FAX)
  203DPI(GP-D320FAX)

• Print Speed

  2~6inch/s(GP-D330FAX)
  2~10inch/s(GP-D320FAX)

• Max. Print Width

  80mm

• Memory

  DRAM:8M FLASH:16M

• Interface

  USB + Ethernet + RJ11 CashDrawer + BT

• Barcode Type

  CODE128、EAN128、ITF、CODE39、EAN13、EAN13+2、 EAN13+5、EAN8、EAN8+2、EAN8+5、CODABAR、POSTNET、 UPC-A、UPC-A+2、UPC-A+5、UPC-E、UPC-E+2、UPC-E+5、 CPOST、MSI、MSIC、PLESSEY、ITF14、EAN14、QRCODE、PDF417

• Character Set

  Commonly used single-byte fonts（ASCII）：FONT 0 to FONT 8
  Simplified Chinese（GB18030）：16×16、24×24、32×32

• Media Typе

  Continuous, die-cut, black mark, fan-fold

• Media Width

  30-85mm

• Label Roll Capacity

  85mm(max)

• Media Thickness

  0.06mm(2.36mil)-0.254mm(10mil)

• Media Core Diameter

  11mm(min）

• Paper Output Method

  Front-paper-exit

• CPU

  Corte-A53(64bit) 8 core

• System Memory

  Standard 2GB RAM+16GB ROM，Option 4GB RAM+ 64G ROM

• Operation System

  Android 7.0

• Micro SD

  TF Card

• Screen

  7 inch 720×1280 IPS LCD

• Touch screen

  Capacitive five-point touch screen

• Wireless

  IEEE 802.11b/g/n 2.4G

• Network

  2G/3G/4G full Netcom, B1/B3/B5/B8/B34/B38/B39/B40/B41

• Speaker

  1×1W

• BT

  BT4.1

• SIM

  Support 25mm×15mm standard card, single card

• NFC

  Support

• Camera

  13-megapixel autofocus

• Interface

  USB OTG+Network port+2 X USB HOST

• Power Adapter Input

  AC100-240V 50/60Hz 2A

• Power Adapter Output

  DC24V 2.5A

• Built-in Battery

  Built-in button battery

• Working Environment

  5~40℃，20~90% non-condensing

• Storage Environment

  -25~55℃，20~93% non-condensing

• Weight

  1.5kg

• Dimension

  206mm×136mm×166mm

• Packing Weight

  2.3kg

• Packing Dimension

  312mm×230mm×225mm

• Cutter Life

  1.5 million cuts

• Print head

  50km

• Printer Certificate

  CE, FCC
