Specification

• Level

  Standard

• Resolution

  GX-2408T: 8dots/mm (203DPI)
  GX-3406T: 12dots/mm (300DPI)

• Max. Print Speed

  GX-2408T: 203mm (8")/Second
  GX-3406T: 152mm (6")/Second

• Max. Print Width

  GX-2408T: 104 mm (4.09")
  GX-3406T: 108.4mm (4.27")

• Max. Print Length

  GX-2408T: 25,400mm (1000")
  GX-3406T: 11,430mm (450")

• Memory RAM

  GX-2408T: 128 MB PSRAM
  GX-3406T: 128 MB PSRAM

• Memory ROM

  GX-2408T: 128 MB Flash
  GX-3406T: 128 MB Flash

• Printing Method

  Thermal Transfer & Direct Thermal

• CPU

  400 MHZ, 32 bit, ARM 9

• Printer language

  Compatible to TSPL, EPL, EPL 2, ZPL, ZPL Il, DPL

• Interface

  · RS-232
  · USB 2.0 High Speed 480Mbps
  · USB Host 2.0, for scanner or PC keyboard
  · lnternal Ethernet 10/ 100Mbps
  · lnternal Bluetooth 4.0 (Optional)
  · lnternal WiFi (Optional)

• Internal fonts

  · 8 alpha-numeric bitmap fonts
  · True type font engine (need download scalable font file)

• Rotation

  Font and barcode support 0, 90, 180, 270 degree

• 1D Barcode

  Code 11, Code 39, Code 93, Code 128 (subsets A, B, C), UPC-A, UPC-E, UCC-128, Codabar, EAN/JAN-8, EAN/JAN-13, Interleaved 2 of 5, ITF14, MSI

• 2D Barcode

  QR Code, Micro QR Code, PDF417, Micro PDF417, MaxiCode, Aztec Code, Data Matrix

• Dealer Option

  · Cutter (Optional)
  · Peeler (Optional)

• Power

  · Input: AC 100-240V, 50-60Hz.
  · Output: DC 24V, 2.5A, 60W

• Physical Dimension

  211mm(W) * 192.3mm(H) * 290.7mm(D)

• Net Weight

  2.56kg

• Certification

  FCC Class A, CE Class A, CCC, BIS, CB

• Environment concern

  Comply with RoHS, REACH, WEEE

• Accessories

  · Windows Label Editing Software, Driver and Operator's Manual CD-ROM
  · 1" ribbon spindle x 2 (for 300m ribbon)
  · Quick Installation Guide
  · External universal switching power supply
  · Power Cord
  · USB Cable
